8a 300v 7/8" Front Panel Mini Change Connectors Rear Side Fastening With Pcb Contacts

Name: 8a 300v 78quot Front Panel Mini Change Connectors Rear Side Fastening With Pcb Contacts
Brand: CABLEFORCE
Price: 1 USD

Wholesale 8a 300v 7/8" Front Panel Mini Change Connectors Rear Side Fastening With Pcb Contacts from china suppliers

Brand Name : CABLEFORCE

Model Number : MF05P4LPAB

Certification : UL Certified, CUL Certified, IP67, IP69K

Place of Origin : Guangdong, China

MOQ : 100

Price : Negotiated

Payment Terms : T/T

Supply Ability : 60000 pcs/month

Delivery Time : 2~3 weeks

Packaging Details : Our standard packing: Individual part with transparent PE bag with label, OEM packing available.

Contacts Poles : 5 Pin

Gender : Female

Termination : PCB Dip Soldering

Contacts plating : Gold

Contacts Carrier : TPU, GF

Protection Degree : IP67, IP68

Screw nut : Brass, CNC, Nickel-plated

Rate current : 13A ,8A

Rated voltage : 300V

Rated temperature : -25℃~+80℃

Contact : Phosphor bronze

Contact Now

8A/300V 7/8"Mini Change Front Panel Connector Rear Side Fastening With PCB Contacts

Connector Technical Data
Model Number	MF05P4LPAB
Connectors No.	A Code
Pollution Degree	5
Rated current	13A, 8A
Rated Voltage	300V
Impulse Voltage	2500V
Screw nut	Brass, CNC, nickel plated
Rated temperature	-25℃~+80℃
Contact carrier	TPU+GF
Termination	PCB Dip Soldering, machine solid pin
Contact	Phosphor bronze
Protection degree	IP67/IP68
Contacts plating	Au(Gold)
Waterproof depth	IP67 1M depth 30 minutes
Connector flamability	UL94 V-0
Certification	RoHS/CE/COC

Description of 7/8"Mini-Change Panel Connector

7/8 inch threaded locking mechanism connector is one of the most important connectors in factory automation and Fieldbus. The 7/8" connectors designed for both power supply and signal transmission, widely used in sensors and actuators, electric motors, packaging and transfer system, outdoor LED module, NMEA 2000 marine navigation and DeviceNet. CABLEFORCE developed and designed the 7/8" plugs and receptacles under the consideration of different harsh industrial conditions and climatic environments.

● 3P, 4P, 5Pin are available
● Meet UL/RoHS/COC/CE
● Degree of protection IP 67/IP 68

● Operating voltage 300V/250V;

● Current range: 13A, 8A

Rear Panel Mount Receptacle

Opposite of front mount.

Threads are on the connector part of the assembly.

Installs from inside the box.

Secured with the O-ring and jam nut on the outside of the box.

Not as easy to replace/requires more forethought than front mounts.

FAQ

● What is s panel mount receptacle?

A receptacle is a plug-like apparatus that allows an electrical device to connect with a supply of electricity.

A connector is a plug-like apparatus that affixes to a receptacle to complete an electrical circuit and deliver electricity.
